New ArcGIS web point feature layers generated by the create feature capability of ArcGIS for AutoCAD will have the raw description prefix assigned by the user or the original default value of the feature layer name.If an existing COGO point group exists with the same name as the web point feature layer (with or without the "esri_" prefix) then those points will initially be included in that point group and the description value used to define the point group will be added to all new points so that they will be recognized by that point group.A new COGO point group will be created with the web point feature layer name (without the "esri_") prefix. COGO points drawn by ArcGIS for AutoCAD from web point feature layers will have a default raw point description that includes the ArcGIS feature layer name as a prefix and the GIS object ID value as a suffix.Upon adding a web feature layer in Civil 3D, the default point feature element type will be COGO points.The following apply to COGO point behaviors in ArcGIS for AutoCAD: COGO point behaviors in ArcGIS for AutoCAD When you're working in Civil 3D, by default ArcGIS for AutoCAD uses COGO points to express point features from web feature layers added to the drawing.ĬOGO points created in ArcGIS for AutoCAD can be used in Civil 3D surfaces, Civil 3D point groups, and other Civil 3D workflows, including any other Civil 3D COGO points. You can change the element type of existing ArcGIS for AutoCAD point features as COGO points using the apply symbol capabilities of ArcGIS for AutoCAD. You can choose any of these element types as the default element type for an ArcGIS for AutoCAD point feature layer. You can use POINT, BLOCK REFERENCE, and COGO POINTS CAD entities interchangeably as the expression of point features in ArcGIS for AutoCAD. FDO feature connections | In ArcGIS for AutoCAD, use ArcGIS web feature layers.Maps | In ArcGIS for AutoCAD use map and image layers.AutoCAD geospatial coordinate definitions | ArcGIS for AutoCAD, assign an Esri coordinate system definition.These are a list of independent geospatial capabilities of the Civil 3D ArcGIS Connecter and their ArcGIS for AutoCAD equivalents: The mapping capabilities of the Autodesk Autodesk Connecter for ArcGIS and its functionality is an independent technology and is not integrated with ArcGIS for AutoCAD. In this release, ArcGIS for AutoCAD supports Civil 3D COGO point entities as valid feature point entities for document feature layers and web feature layers. Integration capabilitiesĪrcGIS for AutoCAD works with a limited number of Civil 3D tools and element types. Additionally ArcGIS for AutoCAD supports the use of COGO points and their related tools in Civil 3D.
Document feature layer name restrictionsĪrcGIS for AutoCAD is a plug-in to AutoCAD and works with the tools and data of AutoCAD.
